PERFORMANCE

Equipped with powerful Cummins tier II engine of large displacement, produce strong Power take-off and boost performance.

Large Digging range and small swing radius, suitable for work in sites with multiple Types.

Powerful Breakout force brings the rapid and perfect work performance into play in any Conditions.

Dynamic Work and operation on slope are stable, side lifting force is powerful, and fully Capable of compound work in a variety of working conditions.

EFFICIENCY
Equipped with hydraulic pump of large flow rate and gear pump of large capacity, operationalization in highly efficient pilot line is realized.

Rapid Boom lifting speed and swing speed distinguish extraordinary loading and Dumping work performance.

Advanced Travel devices provide more robust travel driving force and achieve outstanding Travel performance under slope and wet working conditions.

RELIABILITY

the Hydraulic pipelines adopt upgraded high-pressure hoses to avoid damage and oil Leakage.

Highly Efficient and durable radiator significantly enhances cooling quality and durability.

Wiring Harnesses apply waterproof and dustproof connector and enable high security Level and high reliability.

COMFORT

Expand the area of cabin glass to greater extent. Complete all work in 360 degree Direction comfortably and freely.

EPOS Operating system with advanced technology maximizes work efficiency and reduces Fuel consumption. LCD monitor adopts multi-language and symbol display, and Directly displays working status.

the Air-conditioning system maintains comfortable driving environment under any Working conditions throughout the four seasons with anti-frost and defrosting Functions.

Adjustable Anti-vibrating suspension seat in front and rear directions, equipped with the Functions of adjusting the seat according to driver's weight and lumbar pad.

Key Parameters

Weight	15.8T
Bucket capacity	0.58m3
Engine rated power	112 KW
Flow rate	2*112 L/min
Swing speed	10.1min-1
Travel speed (high/low)	5.04-3.01km/h
Ground specific pressure	35-36kpa
Gradeability (%)	70
Digging force	106.8KN
Boom length	4600mm
Arm length	2500mm

Working Range

Maximum digging depth	5625mm
Maximum digging height	8750mm
Maximum dumping height	6300mm
Maximum digging radius	8160mm
Minimum turning radius	2207mm

Dimensions

a	Transport Length	7662mm
b	Transport Arm height	2980mm
c	Tumblers distance	3035mm
d	Radius of gyration platform end	2202mm
e	Counter Weight ground clearance	894mm
f	Track Gauge	1990mm
g	Total Width of undercarriage	2590mm
h	Width of upper structure	2530mm
i	Width of track shoe	600mm
j	Ground Clearance	412mm
k	Total Length of travel mechanism	4077mm
l	Cabin Height	845mm
