the following example is for you reference.


1.Brief Introduction:

the Meat Flaker frozen meat cutting machine is  for enterprise in meat processing and quick-frozen food processing filed. this machine can directly cut or slice frozen meat(-18 to 0), as a necessary pretreatment step for grinding. It has the advantages of convenient operation, low noise, small vibration, stable capacities, and high productivity.



2.Techincal parameters:


1. Voltage: 380V 50Hz
2. Electrical machine: 7.5KW,1450 round/min
3. Width of the material track: 540mm
4. Hight of the material track: 200mm
5. Operation course of the gas port: 420mm
6. Pressure of operation: 4-5kg/cm2
7. Temprature of frozen meat: -18℃≤T≤0℃
8. Volume of the material lengthwidthhight≤650X500X180mm
9. Thickness of finished blocks: 5mm,10mm,20mm,30mm (slect one kind)
10. Productivity: 1000~4000 kg/hour
(Type of blade 25~50,thickness of finishes blocks 5~30mm )
11. Speed of cutter head: 80 round/min
12. Weight of frozen meat: ≤40Kg
13. Charging method: 200kg material truck
14. Dimension of the formal appearance: (when cylinder rise,the height is 1800mm)
Lengthwidthheight=175010001500mm
15. Weight of machine: 600kg



3.Performance features:

the whole machine is made of stainless steel of high quality to meet the hygienic standard. the lifting cylinder vertical in the rearward, mean that this structure is separated from meat track to avoid pollution of raw material.
