Electrical characteristics

Open circuit voltage (at 25°C)

≥3.65V

Nominal capacity

7000mAh

(at +25°C, battery discharged at continuous current 10mA until voltage reaches cut-off voltage 2.0V. the capacity can vary at different temperature, discharge current or cut-off voltage.)

Maximum continuous current

1000mA

(at +25°C, 2.0V cut-off, battery discharged for minimum 50% of nominal capacity. )

Maximum pulse discharge current

2000mA

(at +25°C, 2.0V cut-off, battery discharged for minimum 50% of nominal capacity with max pulse for 3 seconds after 27 seconds break. the discharged capacity may vary according to the pulse characteristics, the temperature, and the cell's previous history. Fitting the cell with a capacitor may be recommended in severe conditions, consult HCB.)

Storage (recommended)

≤+30°C

(for more severe conditions, consult HCB)

≤75%RH

Operating temperature range

-55°C~+85°C

(Operation above ambient temperature may lead to reduced
Capacity and lower voltage readings at the beginning of pulses, consult HCB.)

Physical characteristics

Diameter

25.6±0.3mm

Height

50.1±0.8mm

Typical weight

53.0g

Li metal content

2.01g
