Model |
Specification |
Price |
120A
Belt |
Production: 80-100 kg / hour
Power: 2.2KW motor, four-pole motor (220V / 1440 rpm)
Template diameter: 120MM
Number of pressure rollers: 2 pieces
Transmission mode: belt, gearbox
Size: 81*42*95cm
Weight: 90kg |
320usd |
120B
Direct connect |
Production: 80-100 kg / hour
Power: 2.2KW motor, four-pole motor (220V / 1440 rpm)
Template diameter: 120MM
Number of pressure rollers: 2 pieces
Transmission mode: coupler
Size: 81*37*95cm
Weight: 90kg |
330usd |
160A
Belt
(motor/diesel dual ) |
Production: 120-160 kg / hour
Power: 4KW motor, four-pole motor (380V 1440 rpm) or matching diesel engine
Template diameter: 160MM
Number of pressure rollers: 2 pieces
Transmission mode: belt, gearbox
Size: 90*45*85cm
Weight: 110kg |
485usd |
160B
Direct connect |
Production: 120-160 kg / hour
Power: 3-4KW motor, Four-pole motor (220V/380V 1440 rpm)
Template diameter: 150MM
Number of pressure rollers: 2 pieces
Transmission mode: coupler
Size: 90*38*85cm
Weight: 110kg |
505usd |
200B
Belt |
Production: 200-300 kg / hour
Power: 7.5-11KW motor, four-pole motor (380V 1440 rpm)
Template diameter: 200MM
Number of pressure rollers: 2 pieces
Transmission mode: belt
Size: 96*52*85cm
Weight: 180kg |
698usd |
200C
Belt
(motor/diesel dual ) |
Production: 200-300 kg / hour
Power: 7.5-11KW motor, Four-pole motor (380V 1440 rpm) or matching diesel engine (12-20 HP)
Template diameter: 200MM
Number of pressure rollers: 2 pieces
Transmission mode: belt, gearbox
Size: 96*52*85cm
Weight: 180kg |
719usd |
200D
Belt (diesel) |
Production: 200-300 kg / hour
Power: Diesel engine (12-20 HP)
Template diameter: 200MM
Number of pressure rollers: 2 pieces
Transmission mode: belt, gearbox
Power structure: clutch
Size: 96*52*85cm
Weight: 180kg |
750usd |
200E
Direct connect |
Production: 200-300 kg / hour
Power: 7.5--11KW motor, four-pole motor (380V 1440 rpm)
Template diameter: 200MM
Number of pressure rollers: 2 pieces
Transmission mode: coupler
Size: 96*40*85cm
Weight: 180kg |
760usd |
230A
Belt |
Production: 400-500 kg / hour
Power: 11--15KW motor, Four-pole motor (380V 1440 rpm)
Template diameter: 230MM
Number of pressure rollers: 2 pieces
Transmission mode: belt
Electricity guide: recommend to equip the current protector (protect the motor, protect personal safety)
Size: 100*45*95cm
Weight: 240kg |
1000usd |
230B
Belt
(motor/diesel dual) |
Production: 400-500 kg / hour
Power: 11--15KW motor, four-pole motor (380V 1440 rpm) or matching diesel engine
Template diameter: 230MM
Number of pressure rollers: 2 pieces
Transmission mode: belt, gearbox
Size: 100*45*95cm
Weight: 240kg |
1020usd |
230C
Direct Connect |
Production: 400-500 kg / hour
Power: 11--15KW motor, Four-pole motor (380V 1440 rpm)
Template diameter: 230MM
Number of pressure rollers: 2 pieces
Transmission mode: shaft drive
Size: 100*45*95cm
Weight: 240kg |
1057usd |
250A
Belt (motor/diesel dual) |
Production: 600-750 kg / hour
Power: 15-18.5KW motor, Four-pole motor (380V 1440 rpm) or matching diesel engine
Template diameter: 250MM
Number of pressure rollers: 2 pieces
Transmission mode: belt, gearbox
Size: 140*55*128cm
Weight: 280kg |
1153usd |
250B
Direct Connect |
Production: 600-750 kg / hour
Power: 15-18.5KW motor Four-pole motor (380V 1440 rpm)
Template diameter: 250MM
Number of pressure rollers: 2 pieces
Transmission mode: coupler
Size: 140*55*128cm
Weight: 280kg |
1190usd |
280
Belt |
Production: 800-1000 kg / hour
Power: 22KW motor Six-pole motor (380V 1440 rpm)
Template diameter: 280MM
Number of pressure rollers: 4 pieces
Transmission mode: belt
Electricity guide: recommend to equip the current protector (protect the motor, protect personal safety)
Size: 150*55*128cm
Weight: 400kg |
1580usd |
300A
Belt (motor/diesel dual) |
Production: 1000-1500 kg / hour
Power: 18.5--22KW motor Four-pole motor (380V 1440 rpm) or matching diesel engine (25-30 HP)
Template diameter: 300MM
Number of pressure rollers: 4 pieces
Transmission mode: belt, gearbox
Size: 163*54*106cm
Weight: 600kg |
1760usd |
300B
Direct Connect |
Production: 1000-1500 kg / hour
Power: 18.5--22KW motor Four-pole motor (380V 1440 rpm)
Template diameter: 300MM
Number of pressure rollers: 3 pieces
Transmission mode: shaft drive
Size: 163*60*106cm
Weight: 600kg |
1800usd |
