| Brand Name: | Dolphinmed |
|---|---|
| Type: | Diagnostic Data Processing Software |
| Place of Origin: | China (Mainland) |
| Model Number: | DOL600Pro |
| name: | DOL600Pro |
Quick Details
Specifications
Ventilation mode |
Adult,Pediatric,Infant(Optional) |
VCV,VC-SIMV,PCV,PC-SIMV, PSV/CPAP with auto Apnea BackupAPRV,PRVC,SIMV-PRVC,Duovent,SmartVent(Optional) NIV,NIV-ST,IPPV,SIPPV,SIMV,PSV,nCPAP,O2 Therapy,NSIPPV, nSIMV(Optional),Standby,ETS Option under Pressure mode | |
Patient type |
Adult,Pediatric,Infant(Optional) |
Tidal Volume |
Adult 150-2000ml;Pediatric 20-350ml;Infant:2-100ml |
Frequency |
Adult:1-100 bpm;Pediatric1-150 bpm;Infant:1-200bpm |
Inspiration time |
Adult&pediatric 0.1-12s,infant:0.1-3s |
Monitoring Parameter |
Ppeak,Pmean,Pplat,PEEP,Vti,Vte,MVe,MV_cont.,MV_spont, F_Ppeak_inspF_Peak_Exp,Leak%,Freq,F_cont,F_spont,%F_Spont,I:E,Ti,Te,Ti/Ttotal,FiO2,(SPO2,EtCO2-Optional),Cstat,CD yn,Rins,Rexp,RSBI,WOB,Auto PEEP,MIP,PO.1 |
Alarm |
Audio and visual alarms |
Volumes |
VTe high/low.Mv MV high/low,TIdal volume not reached,Hlgh leak, |
Pressure |
Peak Pressure high/low,Pressure limitation.02 supply high/low/fail,Air supply pressure high/low/fail,Apnea,Apnea Backup,Freq high/low,FiO2 High/low,Circle Block,Circuit disconnection |
| FIO2 | 21%-100%(0-5 minutes |
Pressure triggeir |
-20-0 cmH20 |
| Pressure Support | 5-120 cmH2O |
| Electronic PEEP | 0-50 cmH20 |
| 100%O2 | 0-5 minutes |
Loops |
P-V,P-V,P-F(optional) |
Power |
AC power fail,Low battery,Battery too low |
Flow trigger |
0-20L/min |
Pressure Control |
5-120cmH20 |
L:E ratio |
1:9.9-9.9:1 adjustable |
| Nebulizer | 0-30 minutes(optional) |
Waveforms |
P-T,F-T,V-T,ETCO2 &SPO2(Optional) |
Recall/Reviews |
1500 alarm events |
| Communication interface | VGA,USB,RJ45 |
| Battery |
120 minutes |
| Air/Oxygen gas supply |
2.4 to 6.0 Bar,Air Compressor(Optional) |
| Trend numerical&graphical | 72 hours |
| Breath to breath waveform review(optional) | 72 hours |
| Net weight | 12kg |
