| Moving Type: | Crawler Bulldozer |
|---|---|
| Condition: | New |
| Brand Name: | Shantui |
| Year: | 2025 |
| Make: | Shantui |
| After-sales Service Provided: | Overseas service center available |
| Dimension(Long * Breadth * High): | 5568x3388x3080mm |
| Machine Weight: | 17600 |
| Model Number: | DH17 |
| Place of Origin: | China (Mainland) |
| Engine Model: | Weichai WD10G190E214 |
| No. of cylinder-bore x stroke: | 6-126mmx130mm |
| Width of track shoe: | 510/560/610mm |
| Blade capacity: | 4.7cbm |
| Color: | Yellow |
Quick Details
Specifications
the following example is for you reference.
1.Brief Introduction:
DH17 dozer is equipped with Linde Hydrostatic Transmission (HST) that allows for Quick- Shift or constantly variablespeed. the HST consists of dual-path closed-cycle systems with two variable displacement piston pumps and twovariable displacement travel motors. Hydrostatic steering eliminates steering clutches and brakes, providing smoothpowerful turs. Fully electronic control provides full automatic shifting and enables smooth control.
MULTI-FUNCTION MONITOR
the mutti-function monitor provides status of themachine, as well as Self-Diagnostic informantionand maintenance reminder.
COMFORTABLE ENVIRONMENT
Equipped with A/C fitted on rear top of cabin, radlo, fan.Sunshade curtain for front and side windows, Equippedwith 24V lighter, USB charging port.
PPC & PCCS CONTROL
PPC (Proportional Pressure Control) ioystickcontrols blade & ripper, PCCS (Palm CommandControl System) foystick controls all directions andspeed movements,
2.Techincal parameters:
Operating welght
17600kg Engine Model
Weichai WD10G190E214 Dlsplacement
9.726L Gross power
140kW(188hp)@1900 Net power
127kW(170hp)@1900 TRavel speed, F
0~10km/h Travel speed, R
0~10km/h Hydraullc oll tank (travel)
60L Hydraullc oll tank (work)
65L Final drive
31/35L/side
3.Performance features:
