Design Features

1. Can be in Dual Junction or Multi-Junction for higher isolation.

2. High RF performance, ultra-competitive Price.

3. Military, space and commercial Applications.



RF Characteristics

Model Number: UIYDC815A8T12

Freq. Range(GHz): 8.0 to 12.0

Insertion Loss Max(dB): 0.5

Isolation Min(dB): 18

VSWR Max: 1.3

Forward Power(W): 30

Reverse Power(W): 30

Connector Type: TAB

Temp.(°C): -55 to +85

Colour:Sliver

Certificate:

ISO 9001
Standard : ISO 9001
Number : 25024Q11063R0S
Issue Date : 06/05/2024
Expiry Date : 06/04/2027
Issued by : ZhongQiu United Intemational Cerification (Beijing)Co., Ld.
Certificate for : Company


ISO 14001
Standard : ISO 14001
Number : 25024E10549R0S
Issue Date : 06/05/2024
Expiry Date : 06/04/2027
Issued by : ZhongQiu United Intemational Cerification (Beijing)Co., Ld.
Certificate for : Company

Other Related Products

RF Isolators

RF Circulators

Attenuator/Termination

RF Filters

Power Divider/Splitter

Duplexer/Triplexer

TX RX Combiner/Splitter

Hybrid Combiner

Directional Coupler

Waveguide to Coaxial Adapter

Applications:

1.    Radar System

2.    Telecom Infrastructure

3.    Microwave Radio Systems

4.    Communication Systems

5.    Wireless Radio Systems

6.    R&D labs

7.    Public Address System Radio Transmitter

8.    Biomedical Instrumentation

9.    4G LTE 5G NR Mobile Communciations



If you have any customized inquiries, Please contact us promptly.
