| Type: | Labeling Machine |
|---|---|
| Automatic Grade: | Automatic |
| Packaging Material: | Plastic |
| Packaging Type: | Bottles |
| Application: | Chemical,Food |
| Condition: | New |
| After-sales Service Provided: | No overseas service provided |
| Dimension(L*W*H): | (L)1120mm (W)728mm (H)1130mm (For reference only) |
| Model Number: | LR465 |
| Brand Name: | AutoPack |
| Place of Origin: | Taiwan |
| Power: | single phase 110/220VAC |
| Voltage: | 50/60Hz |
| Driven Type: | Electric |
Quick Details
Specifications
Features
- Customized industry plastic roller conveyor for accurate placement
- Horizontal wrap station makes label well attached
- Controlled by PLC, touch screen display Output counter
- Adjustable labeling and conveyor speed
- Output counter
- Memory slot, easy to recall the recipe Optimum sensing system offers the most accurate position
- in line application or independent operation
- Modular design for easy maintenance, quick and easy changeover Sanitary SUS#304 and anodized aluminum frame
Options
- Hot stamping date coding machine(PE-300, PM-200)/ink jet printer
- LION LDR6300 clear label sensor
- Mitsubishi PLC and HMI Servo Motor Turnkey linkage with filler, capper, labeler and other in-line systems
Specifications:
- Driven by stepper motor(linear speed: 12M/min)
- Label Width: 10-100mm, Label Length: 20-300mm
- Label Roll: inner diameter 75mm, outer diameter 300mm
- Power: single phase 110/220VAC, 50/60Hz Machine Dimensions: (L)1120mm (W)728mm (H)1130mm (for reference only, the real drawing should be considered as final.)
