| Type: | Other Heat Insulation Materials |
|---|---|
| Brand Name: | LaiGE |
| Type: | calcium silicate board |
| Density: | 250KG |
| Thermal Conductivity: | 0.056 |
| THICKNESS: | 20-120mm |
| Model Number: | HCS-25 |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
1000 C Calcium silicate thermal insulation boards are composed mainly of SiO2, CaO and a little of fiber. It is made by pressing and moulding after chemical reaction under high temperature.
It can be used under 1000C high temperature without deformation, fracture and powdering. It is 100% non-asbestos.
the boards are mainly used in industrial furnaces of steel, electrolytic aluminium, cement, glass, ceramic and so on for refractory and thermal insulation. The products are also used in petrochemistry, building, fireplace, ventilation duct, etc. for fireproof and thermal insulation.
Our company is the largest manufactory of 1000 C calcium silicate thermal insulation boards in China, yearly production up to 70, 000 cubic meters. since 1989 we have begun to produce this kind of boards, which have acquired certificate of ISO 9001 in 2007.
Temperature limitation(Max): 1000 C.
Density: 230 - 400 kg/m3
Size(L x W)): 1000x500mm, 600x300mm, 900x600mm, 1220x1220mm.
Thickness: 25 - 110 mm
It can be used under 1000C high temperature without deformation, fracture and powdering. It is 100% non-asbestos.
the boards are mainly used in industrial furnaces of steel, electrolytic aluminium, cement, glass, ceramic and so on for refractory and thermal insulation. The products are also used in petrochemistry, building, fireplace, ventilation duct, etc. for fireproof and thermal insulation.
Our company is the largest manufactory of 1000 C calcium silicate thermal insulation boards in China, yearly production up to 70, 000 cubic meters. since 1989 we have begun to produce this kind of boards, which have acquired certificate of ISO 9001 in 2007.
Temperature limitation(Max): 1000 C.
Density: 230 - 400 kg/m3
Size(L x W)): 1000x500mm, 600x300mm, 900x600mm, 1220x1220mm.
Thickness: 25 - 110 mm
| Physical Property | Unit |
Typical value | |
| HCS-25 | HCS-27 | ||
| Bulk Density (dry) | Kg / m3 | 250 (±10% ) | 270 (±10% ) |
| Flexural Strength | MPa | ≥ 0.55 |
≥ 0.50 |
| Thermal Conductivity | W / m.K | ≤ 0.056+0.00011t | ≤ 0.058+0.00011t |
| Service Temperature (max. ) | C | 1000 | |
| Linear Shrinkage | % | ≤ 2 (1000 C, 16hrs) | |
